Central Florida's LARGEST Pool Service and Repair Company Over 24 Years of experience - Servicing Central Florida

Equipment

WhisperFlo® Pumps

Description

 Self-priming, high flow with patented Funnel-Flo diffusers

40% glass-filled thermoplastic with the Cam and Ramp "see thru" lid design. Self-priming, high flow with patented Funnel-Flo diffusers. 2 in. suction and discharge ports. Motor features threaded shaft and durable commercial duty 56 frame motor with NEMA square flange.

Featured Highlights

  • Oversized strainer basket and volute
  • Standard and Energy-efficient Square Flange Motors available
  • Lower hp's deliver higher performance than industry standard
  • Compatible with all cleaning systems, various filters and jet action spas
  • Heavy-duty/durable construction. The WhisperFlo® Pump is designed for long life
  • Designed for residential and commercial applications

Product Specifications
011511 - HIGH PERFORMANCE FULL-RATED ENERGY EFFICIENT
011512 - HIGH PERFORMANCE FULL-RATED ENERGY EFFICIENT 60 HZ
011513 - HIGH PERFORMANCE FULL-RATED ENERGY EFFICIENT 60 HZ

  • SF : 1.65
  • Full Load Amps : 14.8/7.8-7.4
  • Wt. : 46
  • Model : WFE-4
  • Voltage : 115/208-230V
  • HP : 1

011514 - HIGH PERFORMANCE FULL-RATED ENERGY EFFICIENT 60 HZ

  • SF : 1.47
  • Full Load Amps : 9.6-8.8
  • Wt. : 54
  • Model : WFE-6
  • Voltage : 208-230V
  • HP : 1 1/2

011515 - HIGH PERFORMANCE FULL-RATED ENERGY EFFICIENT 60 HZ

  • SF : 1.30
  • Full Load Amps : 11.0-10.2
  • Wt. : 55
  • Model : WFE-8
  • Voltage : 208-230V
  • HP : 2

Clean & Clear Filters

The Clean and Clear Filter features a chemical resistant tank

Description
The Clean and Clear Filter features a chemical resistant tank with no-tool servicing and a coreless cartridge for easier cleaning. All models are equipped with easy spin-on unions for plumbing hook-ups. These filters are NSF listed for commercial applications and are available in 50, 75, 100, 150, and 200 square foot sizes.

Featured Highlights

  • NSF listed
  • Unionized connections
  • Integrated continuous High Flow internal air relief
  • Chemical resistant tank body
  • Lock ring with spring-loaded safety latches
  • Coreless cartridge for easy cleaning
  • High Flow manual air relief valve
  • 1 in. drain and wash out
  • Single piece base and body design

Product Specifications
160314 - CLEAN and CLEAR FILTERS
Model : CC 50

  • Effective Filtration Area (Sq. Ft.) : 50
  • Flow Rate (GPM Res) : 50
  • Flow Rate (GPM Comm) : 19
  • Turnover Capacity (In Gallons) 8 Hour : 24,000
  • Turnover Capacity (In Gallons) 10 Hour : 30,000
  • Turnover Capacity (In Gallons) 12 Hour : 36,000
  • Carton Qty : 1
  • Carton Wt (Lbs) : 15

160315 - CLEAN and CLEAR FILTERS
Model : CC 75

  • Effective Filtration Area (Sq. Ft.) : 75
  • Flow Rate (GPM Res) : 75
  • Flow Rate (GPM Comm) : 28
  • Turnover Capacity (In Gallons) 8 Hour : 36,000
  • Turnover Capacity (In Gallons) 10 Hour : 45,000
  • Turnover Capacity (In Gallons) 12 Hour : 54,000
  • Carton Qty : 1
  • Carton Wt (Lbs) : 26

160316 - CLEAN and CLEAR FILTERS
Model : CC 100

  • Effective Filtration Area (Sq. Ft.) : 100
  • Flow Rate (GPM Res) : 100
  • Flow Rate (GPM Comm) : 38
  • Turnover Capacity (In Gallons) 8 Hour : 48,000
  • Turnover Capacity (In Gallons) 10 Hour : 60,000
  • Turnover Capacity (In Gallons) 12 Hour : 72,000
  • Carton Qty : 1 - Carton Wt (Lbs) : 33

160317 - CLEAN and CLEAR FILTERS
Model : CC 150

  • Effective Filtration Area (Sq. Ft.) : 150
  • Flow Rate (GPM Res) : 150
  • Flow Rate (GPM Comm) : 56
  • Turnover Capacity (In Gallons) 8 Hour : 72,000
  • Turnover Capacity (In Gallons) 10 Hour : 90,000
  • Turnover Capacity (In Gallons) 12 Hour : 108,000
  • Carton Qty : 1
  • Carton Wt (Lbs) : 35

160318 - CLEAN and CLEAR FILTERS
Model : CC 200

  • Effective Filtration Area (Sq. Ft.) : 200
  • Flow Rate (GPM Res) : 150
  • Flow Rate (GPM Comm) : 75
  • Turnover Capacity (In Gallons) 8 Hour : 72,000
  • Turnover Capacity (In Gallons) 10 Hour : 90,000
  • Turnover Capacity (In Gallons) 12 Hour : 108,000
  • Carton Qty : 1
  • Carton Wt (Lbs) : 35

​IntelliChlor Salt Chlorinator

IntelliChlor

Description
IntelliChlor takes electrolytic chlorine generation to a higher level of convenience, reliability and safety. Electrolytic Chlorine Generation is the easiest, most effective and convenient way to keep pool water sparkling clean. The IntelliChlor chlorine generator uses common table salt to produce all the chlorine your pool needs, right in your pool – safely, effectively, and automatically. Same sanitation performance as manual chlorine addition without the drawbacks. No need to buy, transport and store expensive chlorine compounds. No more odor, stinging eyes, irritated skin and bleached out swimsuits

Featured Highlights

  • Cell blades are rated for more than 10,000 hours of operation (five years of reliable chlorine output under normal operating conditions)
  • Full diagnostic capabilities, including cell life tracking that communicates remaining hours of cell life in real-time. Captures all performance data daily (production settings, hours of operation, chlorine output, cell cleaning cycles, salt readings, and water temperature averages) making it easy to maintain perfect water
  • Push-button operation and easy-to-view displays enable fast checking of salt levels, cell cleanliness, sanitizer output, and water flow
  • Automatic shut-off feature protects the unit and prolongs cell life under low water temperature conditions
  • Union inlet and outlet connections make cell replacement fast and easy
  • On-time cycling prevents calcium and scale build-up to maximize cell life
  • Ability to communicate with IntelliTouch Automation Systems
  • Certified to UL 1081 standard for safety

Sanitizers

Years of customer use and satisfaction have proven the Rainbow feeders to be the performance leader in pool and spa chemical dispensers.

Rainbow Automatic Chlorine/Bromine Feeders
Years of customer use and satisfaction have proven the Rainbow feeders to be the performance leader in pool and spa chemical dispensers.

Featured Highlights

  • 300 and 320 Series Feeders available in clear and amber for easy tablet level monitoring
  • No special venting required
  • Completely enclosed system
  • No escaping gases
  • All Rainbow Feeders are NSF Listed
  • In-Line Feeders 320 Series. For permanent installation in return line of new or existing pools or spas. Installs in return line on pressure side of pump downstream of all equipment. Standard with 2 in. slip PVC fittings and adapters for 1 1/2 in.
  • Off-Line Feeders 300 Series. Retrofits into existing pools or spas. Operates on pressure side of pump. Uses 1/4 in. feeder hoses, control valve and fittings.

Automation “Pool & Spa Control”

pool or spa control system.

EasyTouch® Control Systems Description
The new EasyTouch®® family offers a new level of control for homeowner’s looking for an affordable, easy to use pool/spa control system. EasyTouch® allows full control of all pool/spa features including advanced features such as colored lighting and IntelliChlor™ chlorine generator support. Every EasyTouch® system includes an easy to use control panel that is built into the outdoor enclosure. This control panel allows for full system setup, programmability, and everyday operation. The EasyTouch® systems come in a variety of configurations: Pool only or Spa only, Pool/Spa with shared equipment, and also integrated with Pentair’s unique IntelliChlor salt chlorine generator.

Featured Highlights

  • All functions controlled with easy, one-button access from the self-contained load center or optional controllers
  • No need to memorize operating sequences, open and close valves, or reset time clocks and thermostats
  • Allows full programmability of every day pool and spa equipment operation for optimum efficiency and variable pool/spa usage patterns
  • Built-in diagnostics include automatic verification of the display, microprocessor, switches, indicators, relay outputs, valve outputs, sensor inputs, and communication ports as well as a diagnostic screen that reports failures for troubleshooting and repair purposes
  • Interfaces with the new IntelliChlor™ automatic chlorine generator
  • Optional controllers for added convenience
  • Indoor control panel (for 4 or 8 circuit systems), Wireless controller (for 4 or 8 circuit systems), QuickTouch 4-function wireless remote, Four-function spa-side remote

Solar Pool Heating

One of the most enjoyable ways to spend leisure time is visiting pool-side with family and friends.

One of the most enjoyable ways to spend leisure time is visiting pool-side with family and friends. Comfortable pool water offers soothing relaxation and recreation while a "too cool" pool just leaves us longing. SwimMaster Plus solar panels can help you get the most out of your pool investment by adding months to your swimming season.

SwimMaster Plus Solar Panels Fine FeaturesPerformance:

SwimMaster Plus solar panels are designed to provide as much heat to your pool as any other solar pool heater. Our proven tube-on-fin absorber captures the sun's rays dawn to dusk, January to December. SwimMaster Plus's 2" diameter, full-flow header distributes pool water to the absorber with maximum efficiency.

Durability:
Several features ensure that SwimMaster Plus solar panel will warm your pool for many years. This model benefits from Solar World's outstanding construction process, including our proven raw material formula, our molded header process and the stress-free results from a tube-on-fin absorber that minimizes the impact of expansion and contraction.

ThermalFlo HP

The environmentally friendly heater that's years ahead of its time.

Description
The environmentally friendly heater that's years ahead of its time.

Featured Highlights

  • Digital controls with dual thermostats offer precise temperature control to maintain the desired separate water temperature in pool/spa combinations without overheating or wasting energy.
  • Self-diagnostic control panel monitors and troubleshoots heat pump operations to ensure safe, dependable operation.
  • Compatible with IntelliTouch and Compool automated control packages
  • Long-life corrosion resistant plastic composite cabinet stands up to severe climates and pool chemicals.
  • High efficiency Trane compressor is the most energy efficient, durable, and quiet compressor available.
  • ETL listed for safe operation

Master Temp

Ultra-high performance in a compact, quiet and eco-friendly design

Description
Ultra-high performance in a compact, quiet and eco-friendly design

Featured Highlights

  • Controls rotate to 3 positions so there’s no need to reverse the header, simplifying installation
  • Quick-change orifice allows easy conversion of gas sources
  • Compact design (21 L x 21W x 28 H) is easy to retrofit, no matter what the space challenges
  • Certified for low NOx emissions
  • Superior "best-in-class" energy-efficiency
  • Built-in carrying handles for easy transport
  • Top-mounted, large format digital display for easy viewing

PoolShark® Vacuum

The PoolShark® effectively cleans all types of in-ground pool surfaces with its multiple row finned footpad.
The PoolShark® effectively cleans all types of in-ground pool surfaces with its multiple row finned footpad. It is available in Gray or Multi-colored versions.
